SWISS TIG 400
Integrated Power Source with Water Cooling UnitUser Friendly Integrated Unit
We are leading SWISS TIG 400 Manufacturers, Suppliers, Dealers, Distributors, Exporters in Pune, Maharashtra is offering best Tig 400 at reasonable rates in Pune, is an IGBT based inverter welding power source with in-built HF unit,cooling unit and water cooling torch for continuous welding applications.
- Digital Voltmeter & Ammeter
- Individual Knobs for easy parameter setting
- In-built trolley with cooling unit & cylinder mount
- Spot welding
Specifications / Technical Data
| Mains supply, V / Ph, Hz | 3Ph-415V±15%50/60/Hz |
| Current @ 60% | 400AMPS |
| Current @ 100% | 310AMPS |
| Power factor | 0.93 |
| Efficiency at maximum current, % | 85 |
| Current range: TIG/MMA, A | 20-400/25-350 |
| 350 Open circuit voltage (OCV), V | 75 |
| Dimensions (WxLxH | 880x400x950 |
| Weight (Kgs) | 40 Kgs |
| Cooling | Water |
| Tanks Capacity | 50 Ltrs |
| Pump Power | 0.5 HP |
