MMA Welding Machine Manufacturers in Pune, Maharashtra. Suppliers, Dealers, Distributors and Exporters in Pune.
Swissweld Technologies Pvt. Ltd., one of the dominant MMA Welding Machine Manufactures, Suppliers Exporters, Dealers and Distributors in Pune, offer the best quality MMA (Manual Metal Arc Welding) machines that are particularly used for joining or welding metals by fusing metals with an electric arc. This machine comes in a semi-automatic mode that requires some manual operation where the welder guides the electrode by hand and a filler metal or stick electrode is used to conduct the welding current.
The new technologies, such as Arc force control and hot start technology, can manage the heat and give precise welding quality in critical applications. Let’s delve into multiple types of our MMA welding machines that are offered by their power and capacity and their features and applications.
What is MMA Welding?
MMA is also known as Manual Metal Arc welding, It is a welding technique which generates an electric arc between metal electrode and the workpiece for fuse metals. MMA welding is basically used in various industries like construction, repair work, shipbuilding, heavy machinery because of its portability and simplicity
Types of MMA welding machine manufacturers:
Being the best MMA welding machine manufacturers, suppliers, exporters, dealers and distributors in Pune, we are providing a wide range of types that are made with strong quality materials and give higher performance. Here we have listed down some types, such as:
- Swiss Arc 200 Amp MMA Welding Machine: This is our commonly used and highly demanded welding machine that has a current range of around 10-200 Amps and comes in lightweight around 7 kg. It is ideal for making welds in thinner metals that require higher accuracy, such as aluminum and stainless steel. The new technological updates, such as smart cooling and eco mode for energy saving, help increase performance by adjusting the speed of fans as per temperature. These are commonly used in home repairs and light metal fabrications.
- Swiss Arc 400 Amp MMA Welding Machine: Our Swiss Arc 400 Amp is known for its higher capacity, has a current range of 20-400 Amps, and comes with a dual voltage capacity that is compatible with 110V and 220V. These machines are made with strong-quality materials for withstanding any kind of environmental conditions. We have added new technological features, such as digital synergic control and anti-stick technology, which are beneficial for simplifying the major task. This technology has an advanced control system that automatically adjusts arc characteristics as per the electrode type and thickness. These are used in industrial equipment manufacturing.
- Swiss Arc 600 Amp MMA Welding Machine: : Our Swiss Arc 600 Amp machine is highly used in large industrial applications such as pipeline welding and heavy structure welding. It has a current range of up to 20-600 Amp and can handle the most demanding industrial applications, including thick and heavy metals. The new updated digital dual display and real-time adaptive arc control technology unlock the door of multiple options that can be for taking readings of voltage and current and real-time compensating for changes in joint position and electrode angle. Due to its multiple features, these are highly applicable in shipbuilding, offshore construction and heavy structural welding.
Technical Specifications of MMA Welding Machine:
We have attached below a technical sheet of MMA welding machine that gives a more details about our each types such as:
| Specification | Swiss Arc 200 Amp | Swiss Arc 400 Amp | Swiss Arc 600 Amp |
|---|---|---|---|
| Model | Swiss Arc 200 | Swiss Arc 400 | Swiss Arc 600 |
| Current Range (A) | 10 - 200 A | 20 - 400 A | 30 - 600 A |
| Input Voltage | 230V ± 15%, 50/60 Hz | 380V ± 15%, 50/60 Hz | 380V ± 15%, 50/60 Hz |
| Duty Cycle | 60% at 200 A | 60% at 400 A | 60% at 600 A |
| Power Factor | 0.93 | 0.93 | 0.93 |
| No-Load Voltage (V) | 60V | 72V | 80V |
| Efficiency (%) | 85% | 88% | 90% |
| Protection Class | IP21 | IP23 | IP23 |
| Insulation Class | F | F | F |
| Cooling System | Forced Air Cooling | Forced Air Cooling | Forced Air Cooling |
| Arc Force Adjustment | Yes | Yes | Yes |
| Hot Start | Adjustable | Adjustable | Adjustable |
| Anti-Stick Function | Yes | Yes | Yes |
| Welding Electrode Type | All electrodes up to 4.0 mm | All electrodes up to 6.0 mm | All electrodes up to 8.0 mm |
| Digital Display | Yes | Yes | Yes |
| Electrode Holder Cable | 3m | 4m | 5m |
| Earth Clamp Cable | 2.5m | 3.5m | 4.5m |
| Overheating Protection | Yes | Yes | Yes |
| Voltage Adjustment | Stepless | Stepless | Stepless |
Features of MMA Welding Machine:
As a former MMA welding machine suppliers and exporters in Pune, our all machines are made with multiple types of features that give various benefits such as:
| Category | Features | Benefits | Technological Updates |
|---|---|---|---|
| 1. Power Source | Our all types of MMA welding machine comes with digital inverter technology | It improves the energy efficiency | Improved power factor and reduced energy consumption |
| 2. Control System | These machines are equipped with advanced microprocessor control | Precise arc control and stability | Smart controls for adaptive welding parameters |
| 3. Weight | It has lightweight and portable design | Easy transportation and handling | Compact designs utilizing modern materials |
| 4. User Interface | Intuitive digital displays | User-friendly operation | Touchscreen interfaces with real-time feedback |
| 5. Electrode Compatibility | Wide range of electrode sizes | Versatility for different welding applications | Enhanced electrode feed mechanisms |
| 6. Safety Features | Our MMA welding machine has the overload protection and thermal management | Increased operator safety | Automatic shutdown features |
| 7. Connectivity | Bluetooth/Wi-Fi connectivity | Remote monitoring and control | Integration with welding management software |
| 8. Duty Cycle | Increased duty cycles | Longer operation without overheating | Advanced cooling systems for prolonged use |
Applications of MMA Welding Machine:
As a former MMA welding machine suppliers and exporters in Pune, our all machines are highly applicable in multiple applications such as:
- Fabrication of metal structures and frames
- Repair of heavy machinery and equipment
- Welding of pipelines and fittings
- Construction of automotive and aerospace parts
- Metals art and sculpture creation
- Joining of cast iron components
- Welding in shipbuilding and repair
- Maintenance work in industrial settings
- Production of agricultural equipment parts
- Building construction and reinforcement work
Being the top MMA welding machine manufacturers , suppliers, exporters, dealers and distributors in Pune, we are offering the quality MMA welding machine at reasonable price that are made with strong quality of materials and able to withstand in outer environment. The new technological updates and mechanism helps these machines to perform more in the large industrial sectors. For more information, contact us today.
